Miscellaneous Imager Options
128
Timeout Between Decodes, Same Symbol
Parameter # 137 (SSI # 89h)
Use this option in Continuous Bar Code Read mode to prevent the beeper from continuously beeping when a bar
code is left in the RS6000 field of view. The bar code must be out of the field of view for the timeout period before
the RS6000 reads the same consecutive bar code. It is programmable in 0.1 second increments from 0.0 to 9.9
seconds. The default interval is 0.5 seconds.
To select the timeout between decodes for the same bar code, scan the bar code below, then scan two numeric
bar codes from Alphanumeric and Numeric Bar Codes that correspond to the desired interval, in 0.1 second
increments.
Timeout Between Decodes, Same Symbol
