Figure 42 10-Slot WT6000/RS6000 Charge Only Cradle Setup

Charging the WT6000

To Charge the WT6000:

1. Insert the WT6000 in the WT6000 charging slot.

Figure 43 Insert WT6000 into Cradle

2. Ensure that the WT6000 is properly seated in the charging slot.

AC Line Cord

DC Line Cord

Power Input

Power Supply
