Symbologies
198
I 2 of 5 Reduced Quiet Zone
Parameter # 1210 (SS
I # F8h 04h BAh)
Scan one of the following bar codes to enable
or disable decodi
ng I 2 of 5 bar codes with reduced quiet zones. If
you select
Enable
, select a
1D Quiet Zone Level on page 242
.
Enable I 2 of 5 Reduced Quiet Zone
(1)
*
Disable I 2 of 5 R
educed Quiet Zone
(0)
197
199
