Zebra RS6000 User Manual

Getting Started
22
Figure 4 Install the Battery
Remove the Battery
1. Hold the RS6000 in one hand.
2. Use finger tip to press the battery release latch.
Figure 5 Remove Battery
3. While holding down the battery release latch, pull up the battery to release it from the locking slots of the
RS6000.
Wearing the RS6000
1. Slide the RS6000 onto the index and middle fingers with the scan trigger next to the thumb.
2. Tighten the finger strap.
Locking Slot
Battery
Battery Release Latch
2
3
1
1
2
