20-Slot Battery Charger

The 20-Slot Battery Charger charges up to 20 spare batteries.

Figure 51 20-Slot Battery Charger

Figure 52 20-Slot Battery Charger

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 280.

Battery Charging LEDs (20)

Power LED

Input Power

AC Line Cord

Power Supply

DC Line Cord
