Zebra RS6000 - Scan Data Transmission Format

To Next Page

To Previous Page

Miscellaneous Imager Options

136

Scan Data Transmission Format

Parameter # 235 (SSI #

EBh)

To change the scan data format, scan one of the following eight bar codes corresponding to the desired format.

Scan Prefix

(7)

Scan Suffix 1

(6)

Scan Suffix 2

(8)

Data Format Cancel

NOTE: If using this parameter do not use ADF rules to set the prefix/suffix.
