Zebra RS6000 User Manual

Maintenance and Troubleshooting
290
6. Using the saved screws from the Triggerless Assembly, install the contact block onto the RS6000 with a T6
Torx screwdriver. Torque screws to 2 kgf-cm.
Figure 65 Installing Contact Block
7. Install the Trigger Assembly. See Trigger Assembly Installation on page 287.
Convert to Triggerless Assembly
To convert from the Trigger Assembly to the Triggerless Assembly:
1. Turn the RS6000 upside-down.
2. Remove the Trigger Assembly. See Trigger Assembly Removal on page 287.
3. Remove and save the four screws securing the contact block to the housing using a T6 Torx screwdriver.
4. Lift the contact block off the RS6000.
5. Remove the O ring from the contact block and install it on the Triggerless Assembly. See Figure 64.
6. Lower the Triggerless Assembly onto the RS6000.
Figure 66 Installing Triggerless Assembly
Contact Block
