Inverse 1D

Parameter # 586 (SSI # F1h 4Ah)

This parameter sets the 1D inverse decoder setting. Options are:

• Regular Only - the RS6000 decodes regular 1D bar codes only.

• Inverse Only - the RS6000 decodes inverse 1D bar codes only.

• Inverse Autodetect - the RS6000 decodes both regular and inverse 1D bar codes.

*Regular

(0)

Inverse Only

(1)

Inverse Autodetect

(2)
