Accessories

2-Slot WT6000/RS6000 USB Charging Cradle

The 2-Slot WT6000/RS6000 Charging Cradle:

• provides 5.4 VDC (nominal) power for operating the WT6000 and RS6000.

• provides USB communication with a host computer.

Figure 33 2-Slot WT6000/RS6000 Charging Cradle

NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 280.

RS6000 Charging LED

RS6000 Charging Slot

Power LED

WT6000 Charging Slot

WT6000 Charging LED
