Symbologies

153

Decode UPC/EAN/JAN Supplementals (continued)

Enable 414/419/434/439 Supplemental Mode

(6)

Enable 491 Supplemental Mode

(8)

Enable Smart Supplemental Mode

(3)

Supplemental User-Programmable Type 1

(9)

Supplemental User-Programmable Type 1 and 2

(10)

Smart Supplemental Plus User-Programmable 1

(11)

Smart Supplemental Plus User-Programmable 1

and 2

(12)
