Zebra RS6000 - Page 248

To Next Page

To Previous Page

OCR Programming

248

OCR-A Variant (continued)

Special banking characters output as the following representative characters:

outputs as f

outputs as c

outputs as h

NOTE: Enable OCR-A before setting this parameter. If disabling OCR-A, set the variant to its default

(OCR-A Full ASCII).

*OCR-A Full ASCII

(0)

OCR-A Reserved 1

(1)

OCR-A Reserved 2

(2)

OCR-A Banking

(3)
