OCR Programming

255

OCR Orientation (continued)

*OCR Orientation 0

o

(0)

OCR Orientation 270

o

Clockwise

(1)

OCR Orientation 180

o

Clockwise

(2)

OCR Orientation 90

o

Clockwise

(3)

OCR Orientation Omnidirectional

(4)
