Programming Reference
321
EAN.UCC
Composites (GS1
DataBar, GS1-128,
2D portion of UPC
composite)
Native mode transmission.
Note: UPC portion of composite is transmitted using UPC rules.
0 Standard data packet.
1 Data packet containing the data following an encoded symbol
separator character.
2 Data packet containing the data following an escape mechanism
character. The data packet does not support the ECI protocol.
3 Data packet containing the data following an escape mechanism
character. The data packet supports the ECI protocol.
GS1-128 emulation
Note: UPC portion of composite is transmitted using UPC rules.
1 Data packet is a GS1-128 symbol (i.e., data is preceded with ]JC1).
PDF417,
Micro PDF417
0 Reader set to conform to protocol defined in 1994 PDF417 symbology
specifications. Note: When this option is transmitted, the receiver
cannot reliably determine whether ECIs have been invoked or whether
data byte 92
DEC
has been doubled in transmission.
1 Reader set to follow the ECI protocol (Extended Channel
Interpretation). All data characters 92
DEC
are doubled.
2 Reader set for Basic Channel operation (no escape character
transmission protocol). Data characters 92
DEC
are not doubled. Note:
When decoders are set to this mode, unbuffered Macro symbols and
symbols requiring the decoder to convey ECI escape sequences
cannot be transmitted.
3 The bar code contains a GS1-128 symbol, and the first codeword is
903-907, 912, 914, 915.
4 The bar code contains a GS1-128 symbol, and the first codeword is in
the range 908-909.
5 The bar code contains a GS1-128 symbol, and the first codeword is in
the range 910-911.
Example: A PDF417 bar code ABCD, with no transmission protocol enabled, is transmitted
as ]L2ABCD.
Data Matrix 0 ECC 000-140, not supported.
1 ECC 200.
2 ECC 200, FNC1 in first or fifth position.
3 ECC 200, FNC1 in second or sixth position.
4 ECC 200, ECI protocol implemented.
5 ECC 200, FNC1 in first or fifth position, ECI protocol implemented.
6 ECC 200, FNC1 in second or sixth position, ECI protocol
implemented.
Table 31 Modifier Characters (Continued)
Code Type Option Value Option
