6166 DC Voltage Current Source Operation Manual
6.2.1 Status Register
6-9
Common conditions in which the Status Byte Register is cleared
• All cleared when the power is turned ON.
• All cleared by *CLS except that MAV is not cleared if data exists in the output buffer.
• Not cleared even if read by *STB?.
Conditions in which the Service Request Enable Register is cleared
• Cleared when the power is turned ON.
• Cleared when the *SRE0 command is executed.
Table 6-1 Status Byte Register (STB)
bit Name Description
0 Not in use Always set to 0
1 Not in use Always set to 0
2EAV
Error Available
ON: Set to 1 when error information is stored in Error Queue.
OFF: Set to 0 when Error Queue is read and becomes empty.
3DSB
Device Event Summary Bit
ON: Set to 1 when any of the DESR incidents occurs and the bit is set to 1,
if the corresponding DESER bit is also 1.
OFF: Set to 0 when DESR is cleared by reading (DSR?).
4MAV
Message Available
ON: Set to 1 when output data is entered in the output buffer.
OFF: Set to 0 when the output buffer is read and becomes empty.
5ESB
Standard Event Summary Bit
ON: Set to 1 when any of the SESR incidents occurs and the bit is set to 1,
if the corresponding SESER bit is also 1.
OFF: Set to 0 when SESR is cleared by reading (*ESR?).
6MSS
Master Summary
ON: Set to 1 when any of the STB incidents occurs, if the corresponding
SRER bit is 1.
RQS
Request Service
ON: Set to 1 when MSS is set to 1, and SRQ is generated.
OFF: Set to 0 when STB is read by a serial poll.
7 Not in use Always set to 0
