6166 DC Voltage Current Source Operation Manual
6.2.1 Status Register
6-10
Common conditions in which the Standard Event Status Register is cleared
• All cleared when the power is turned ON.
• All cleared by *CLS.
• All cleared when read by *ESR?.
Conditions in which the Standard Event Status Enable Register is cleared
• Cleared when the power is turned ON (the PSC flag is set to 1).
• Cleared when the *ESE0 command is executed.
Table 6-2 Standard Event Status Register (ESR)
bit Name Description
0OPC
Operation Complete
ON: Set to 1 when all operation is completed after receiving the *OPC
command.
1 Not in use Always set to 0
2 Not in use Always set to 0
3 Not in use Always set to 0
4EXE
Execution Error
ON: Set to 1 when a received command is not currently executable.
Set to 1 when incorrect data is entered in a command parameter.
5CME
Command Error
ON: Set to 1 when the received command is incorrectly spelled.
6 Not in use Always set to 0
7 PON ON: Set to 1 when the power is turned ON.
Table 6-3 Device Event Status Register (DSR) (1 of 2)
bit Name Description
0OVL
Over Load
ON: Set to 1 when overload is detected.
Not reset to 0 even if the overload is canceled.
1FSP
Fan Stop
ON: Set to 1 when fan stop is detected.
Not reset to 0 even if the fan stop is canceled.
2OVH
Over Heat
ON: Set to 1 when overheat is detected.
Not reset to 0 even if the overheat is canceled.
3SUE
Source Unit Error
ON: Set to 1 when a source unit error occurs.
4PVL
Plus Volt Limiter
ON: Set to 1 when the positive voltage limiter is detected.
5MVL
Minus Volt Limiter
ON: Set to 1 when the negative voltage limiter is detected.
6PIL
Pulse I Limiter
ON: Set to 1 when the positive current limiter is detected.
To Next Page
