6166 DC Voltage Current Source Operation Manual
3.3.3 Outputting Voltage with Rotary Knob (Auto Range)
3-13
The following table shows the source ranges when auto range is selected.
CAUTION:
When the 6161-compatible operation is set to OFF:
1. Changing the source value from less than 55 V to 55 V or higher in Operate status sets the output status to
Standby as hazardous voltage.
When the 6161-compatible operation is set to ON:
2. Changing the range to 1000 V from another range in Operate status sets the output status to Standby.
3. If the OPT6166+20 (1 mA/10 mA: compliance voltage 1200 V) is installed, changing the range to 1 mA or
10 mA from another range in Operate status sets the output status to Standby.
Regardless of the 6161-compatible operation:
1. Switching the source function in Operate status sets the output status to Standby.
For more information on the 6161-compatible operation, refer to Section 6.1.2, "Compatibility with Former
Model."
Table 3-4 Source Ranges for Auto Range
Source function Range Source range
Divider voltage 10 mV 00.00000 to 11.99999 mV
100 mV 012.0000 to 119.9999 mV
1000 mV 0120.000 to 1199.999 mV
Voltage 1 V 0.000000 to 1.199999 V
10 V 01.20000 to 11.99999 V
100 V 012.0000 to 119.9999 V
1000 V 0120.000 to 1199.999 V
Current 1 mA 0.000000 to 1.199999 mA
10 mA 01.20000 to 11.99999 mA
100 mA 012.0000 to 119.9999 mA
To Next Page
