6166 DC Voltage Current Source Operation Manual
2. PANEL DESCRIPTIONS
2-1
2. PANEL DESCRIPTIONS
This chapter describes the part names and functions on the front and rear panels, and the annotations dis-
played on the screen.
The basic operations are described in Chapter 3, "BASIC OPERATION."
The applied functional operations are described in Chapter 4, "FUNCTION REFERENCE" and Chapter 5,
"OPERATIONAL DESCRIPTIONS."
2.1 Front Panel
This section describes the panel keys or connectors in each section on the front panel.
Figure 2-1 Front Panel
The front panel is divided into the following sections:
1. Display section
2. DATA ENTRY section
3. RANGE section
4. POLARITY section
5. LIMIT/DIVIDER section
6. PROGRAM section
7. MENU/DISPLAY section
8. CURSOR section
9. OUTPUT section
10. DIGIT section
11. Front output terminals
12. POWER switch
