6166 DC Voltage Current Source Operation Manual
1.5.2 Power Supply Specifications
1-5
1.5.2 Power Supply Specifications
The following table shows the 6166 power supply specifications.
CAUTION: To prevent damage to the 6166, do not apply a voltage or frequency that exceeds the specified
range.
Ensure that the power voltage setting on the rear panel matches the voltage of the commercial power sup-
ply.
Figure 1-2 Power Voltage Indicator
Table 1-4 Power Supply Specification
Standard
Optional
32 42 44
100 VAC 120 VAC 220 VAC 240 VAC
Input voltage range 90 V to 110 V 108 V to 132 V 198 V to 242 V 207 V to 250 V
Frequency range 48 Hz to 66 Hz
Power consumption 90 VA or less
Fuse T2.5 A/250 V T1.25 A/250 V
Voltage setting indicator
