ADCMT 6166 - Saving Parameters

6166 DC Voltage Current Source Operation Manual
3.12.2 Saving Parameters
3-82
3.12.2 Saving Parameters
The setting parameters can be saved to the non-volatile memory, areas USER0 to USER3 separately.
The 6166 can start up with the parameters saved in USER0 at power ON.
For information on how to load the parameters, refer to Section 3.12.3, "Loading Parameters."
For information on how to start the 6166 with the parameters saved in USER0, refer to Section 3.12.1,
"Auto Parameter Loading at Power ON."
The following is an example to save the parameters to USER3.
Operating procedure
Press . The screen is switched to the menu screen.
The MENU key lights up during menu screen display.
Example display
Press or to select PARAM.
Example display
1 2 3 54 7
6
8
1
2
