ADCMT 6166 - Saving Program Memory

6166 DC Voltage Current Source Operation Manual
3.8.3 Saving Program Memory
3-41
3.8.3 Saving Program Memory
The data input in the program memory is saved in the volatile memory (RAM). When the 6166 is turned
OFF, the data is erased.
To prevent it, the data needs to be saved to the non-volatile memory.
The saved data is automatically copied to the volatile memory (ROM) when the 6166 is turned ON.
The following shows the procedure of saving the program memory.
Operating procedure
Check that the source value screen is displayed.
If the menu screen, limit setting screen or numeric keypad input screen is displayed, press the EXIT
key.
If the program function has been already enabled, go on to Step .
Press . The program function is enabled and the program screen is displayed.
While the program screen is displayed, the PROGRAM key lights up.
Example display Program screen
Press . The memory saving screen is displayed.
Example display Memory saving screen
12 3
1
3
2
3
