6166 DC Voltage Current Source Operation Manual
6.6.2 Data Format
6-29
6.6.2 Data Format
The 6166 uses the following data types for data input and output.
1. Numeric data
There are three numeric data formats, any of which can be used for input.
Some commands can add units to the data when the data is input.
• Integer type: NR1 format
• Fixed-point type: NR2 format
• Floating-point type: NR3 format Code
2. Units
The table below lists the units that can be used for the D command.
The D command is valid in the 6161-compatible mode.
Unit Exponent Meaning
V 10+0 Voltage
MV 10-3 Voltage
A 10+0 Current
MA 10-3 Current
[Sign]
Numeric
Numeric
Numeric
[Sign]
