6166 DC Voltage Current Source Operation Manual
6.5.3 BCD Interface Signals
6-24
6.5.3 BCD Interface Signals
The following tables shows the signal list of the BCD interface connector.
Table 6-7 BCD Interface Signals
Pin number Input/output Signal name Pin number Input/output Signal name
1 - GND 26 IN 10^6 (A)
2 IN 10^0 (A) 27 * NC
3 IN 10^0 (B) 28 * NC
4 IN 10^0 (C) 29 * NC
5 IN 10^0 (D) 30 * NC
6 IN 10^1 (A) 31 * NC
7 IN 10^1 (B) 32 * NC
8 IN 10^1 (C) 33 * NC
9 IN 10^1 (D) 34 IN V/I MODE
10 IN 10^2 (A) 35 IN RANGE_0
11 IN 10^2 (B) 36 IN RANGE_1
12 IN 10^2 (C) 37 IN POL
13 IN 10^2 (D) 38 IN DIVIDER
14 IN 10^3 (A) 39 * NC
15 IN 10^3 (B) 40 * NC
16 IN 10^3 (C) 41 IN VL_0
17 IN 10^3 (D) 42 IN VL_1
18 IN 10^4 (A) 43 IN IL_0
19 IN 10^4 (B) 44 IN IL_1
20 IN 10^4 (C) 45 * NC
21 IN 10^4 (D) 46 OUT LMT_FLAG
22 IN 10^5 (A) 47 IN OPR_IN
23 IN 10^5 (B) 48 OUT OPR_OUT
24 IN 10^5 (C) 49 * NC
25 IN 10^5 (D) 50 * NC
