6166 DC Voltage Current Source Operation Manual
6.5.3 BCD Interface Signals
6-25
NC: Not connected
Used connector
57-40500 Amphenol (Unit side)
57-30500 Amphenol (Cable side)
(1) Function and range setting
*1 When the current function is selected, setting DIVIDER to ON generates an error.
*2 When the range is set to 1000 V, setting DIVIDER to ON generates an error.
*3 When the current function is selected, setting both RANGE_1 and RANGE_2 to ON generates
an error.
(2) Polarity setting
Range setting
specification
V/I MODE (34) RANGE_1 (36) RANGE_0 (35) DIVIDER (38)
10 mV0001
100 mV 0 0 1 1
1000 mV 0 1 0 1
1 V0000
10 V 0 0 1 0
100 V 0 1 0 0
1000 V 0 1 1 0
*20111
1 mA 1 0 0 *1
10 mA101*1
100 mA 1 1 0 *1
*3111
Polarity
setting specification
POL (37)
+0
-1
