6166 DC Voltage Current Source Operation Manual
3.10.2 Setting Type of Thermocouple
3-70
For information on how to set the temperature using the rotary knob, refer to Section 3.3, "Setting Source
Value Using Rotary Knob."
NOTE:
• The temperature setting range varies depending on the type of thermocouple. For more information, refer
to Table 3-12, "Types of Thermocouples and Setting Temperature Ranges."
• When the thermal electromotive force function is enabled, the source function cannot be switched to the
voltage function or current function.
3.10.2 Setting Type of Thermocouple
The thermocouple for the thermal electromotive force function is selectable from the following eight
types.
Also, the JIS Standard is selectable from either JIS C1602-1995 or JIS C1602-1981.
JIS C1602
Thermocouple 1995 1981
T (CC)
J (IC)
E (CRC)
K (CA)
S (PR10)
R (PR13)
B (PR30)
N-
NOTE:
When thermocouple type N is selected, JIS C1602-1995 will be
applied even if JIS C1602-1981 is selected for the JIS standard.
The temperature setting value is saved for each thermocouple.
Thus, changing the type of thermocouple changes the temperature
setting value too.
