3.2.4 Source Range
3-6
3.2.4 Source Range
The following table shows the relationship between the input values and the source ranges in setting the
source value using the numeric keypad.
CAUTION:
When the 6161-compatible operation is set to OFF:
1. Changing the source value from less than 55 V to 55 V or higher in Operate status sets the output status to
Standby as hazardous voltage.
When the 6161-compatible operation is set to ON:
2. Changing the range to 1000 V from another range in Operate status sets the output status to Standby.
3. If the OPT6166+20 (1 mA/10 mA: compliance voltage 1200 V) is installed, changing the range to 1 mA or
10 mA from another range in Operate status sets the output status to Standby.
Regardless of the 6161-compatible operation:
1. Switching the source function in Operate status sets the output status to Standby.
2. The divider voltage is output from the DIVIDED OUT terminal.
For more information on the 6161-compatible operation, refer to Section 6.1.2, "Compatibility with Former
Model."
Table 3-1 Source Ranges
Source function Range Fixed range Auto range
Divider voltage 10 mV
100 mV
1000 mV
00.00000 to 11.99999 mV
000.0000 to 119.9999 mV
0000.000 to 1199.999 mV
00.00000 to 11.99999 mV
012.0000 to 119.9999 mV
0120.000 to 1199.999 mV
Voltage 1 V
10 V
100 V
1000 V
0.000000 to 1.199999 V
00.00000 to 11.99999 V
000.0000 to 119.9999 V
0000.000 to 1199.999 V
0.000000 to 1.199999 V
01.20000 to 11.99999 V
012.0000 to 119.9999 V
0120.000 to 1199.999 V
Current 1 mA
10 mA
100 mA
0.000000 to 1.19999 9 mA
00.00000 to 11.99999 mA
000.0000 to 119.9999 mA
0.000000 to 1.199999 mA
01.20000 to 11.99999 mA
012.0000 to 119.9999 mA
