6166 DC Voltage Current Source Operation Manual
3.2.3 Outputting Divider Voltage with Numeric Keypad
3-5
Press to set the source value to +100 mV.
When the divider voltage function is set to ON, the DIVIDER key goes ON.
• When the unit is previously set to "mV," entering can be omitted.
• To set the polarity to negative, press while entering the numeric value.
Example display
Press to output the source value (Operate). While the source value is output, the
OPERATE key lights up.
Press again to stop the output (Standby). The OPERATE key goes OFF.
To Next Page
