6166 DC Voltage Current Source Operation Manual

1.4 Options

1-3

1.4 Options

The 6166 has the following options:

For power supply options, refer to Section 1.5.2, "Power Supply Specifications."

1.5 Operating Environment

This section describes the required environmental and power supply conditions.

1.5.1 Environmental Conditions

The 6166 must be installed in an environment meeting the following conditions:

• Operating environment: Ambient temperature 0C to +50C

Relative humidity 85 % or lower without condensation

• Storage environment Ambient temperature -25C to +70C

Relative humidity 85 % or lower without condensation

• Location not subject to corrosive gasses

• Away from direct sunlight

• Dust free

• Vibration free

• Noise free

The 6166 is designed with full consideration given to the noise contained in the AC power line. Nev-

ertheless, it is recommended that the 6166 be used in an environment with as little line noise as pos-

sible.

If line noise is unavoidable, use a noise filter.

• Positioning of the 6166

A cooling fan is located on the rear panel and vents are located on the side panels. Blocking the fan

or vents causes the internal temperature to rise, possibly causing faulty operation.

Leave at least 10 cm of free space between the rear panel and the wall. Also, do not position the

6166 with the rear panel facing down.

• Mounting in a rack

Ensure that exhaust air from other devices is not directed at the vents on the side of the 6166.

To prevent the temperature in the rack from rising, install a heat sink fan.

Table 1-3 Option List

Option number Description

OPT6166+04 BCD parallel interface

OPT6166+20 Compliance voltage 1200 V in the 1 mA and 10 mA ranges

ADCMT 6166 User Manual
