6166 DC Voltage Current Source Operation Manual
6.5.3 BCD Interface Signals
6-26
(3) Voltage/current limit setting
(4) Operate/Standby
(5) Limiter signal output
(6) Operate signal output
Voltage limit VL_1 (42) VL_0 (41)
10 V 0 0
130 V 0 1
300 V 1 0
1250 V 1 1
Voltage limit IL_1 (44) IL_0 (43)
5 mA 0 0
13 mA 0 1
50 mA 1 0
125 mA 1 1
Setting specification LMT_FLAG (46)
Standby 0
Operate 1
Output specification OPR_IN (47)
Undetected 0
Detected 1
Output specification OPR_OUT (48)
Standby 0
Operate 1
