6166 DC Voltage Current Source Operation Manual
6.3.3 Setting GPIB
6-16
6.3.3 Setting GPIB
There are three setting items for GPIB: GPIB address, header and Listen only.
This section describes how to set them.
Referring to Section 6.1.1, "Selecting Interface," select the GPIB interface in advance.
(1) Setting the GPIB address
Operating procedure
Press . The menu screen appears.
The MENU key lights up during menu screen display.
Example display
Press or to select I/F.
Example display
Press to move the Select level.
Example display
Press or to select Address.
The highlight section switches as Bus  Address  6161 Compati.
Example display
Press to move to the Input/Run level.
Example display
1
2
3
4
5
