6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-1
9. SPECIFICATIONS
The 10 mV to 1000 mV ranges are divided output.
Voltage source range:
Current source range:
Common accuracy: At constant power and load, with a compliance voltage of 10 V or less
Overall accuracy: Includes calibration accuracy, 1-day stability, temperature coefficient, and lin-
earity.
At temperature of 23C5C and relative humidity of 70 % or less
Relative accuracy: Equal to the overall accuracy excluding the external standard traceability,
at temperature of 23C1C.
1-day stability: At temperature of 23C1C
Temperature coefficient 1: At temperature of 23C10C
Temperature coefficient 2: At temperature of 0C to 13C, 33C to 50C
Voltage source:
Range Source range Setting resolution
10 mV 0 to 11.99999 mV 10 nV
100 mV 0 to 119.9999 mV 100 nV
1000 mV 0 to 1199.999 mV 1 V
1 V 0 to 1.199999 V 1 V
10 V 0 to 11.99999 V 10 V
100 V 0 to 119.9999 V 100 V
1000 V 0 to 1199.999 V 1 mV
Range Source range Setting resolution
1 mA 0 to 1.199999 mA 1 nA
10 mA 0 to 11.99999 mA 10 nA
100 mA 0 to 119.9999 mA 100 nA
Range
Overall accuracy (1 year) Overall accuracy (180 days) Overall accuracy (90 days) Overall accuracy (1 day)
(% of setting + V)
10 mV 0.0070 + 2.3 V 0.0065 + 2.3 V 0.0060 + 2.3 V 0.0055 + 0.7 V
100 mV 0.0055 + 2.5 V 0.0050 + 2.5 V 0.0045 + 2.5 V 0.0040 + 0.8 V
1000 mV 0.0045 + 8 V 0.0040 + 8 V 0.0035 + 8 V 0.0030 + 6 V
1 V 0.0035 + 12 V 0.0030 + 12 V 0.0025 + 11 V 0.0020 + 10 V
10 V 0.0035 + 70 V 0.0030 + 70 V 0.0025 + 70 V 0.0020 + 60 V
100 V 0.0035 + 700 V 0.0030 + 700 V 0.0025 + 700 V 0.0020 + 600 V
1000 V 0.0040 + 7 mV 0.0035 + 7 mV 0.0030 + 7 mV 0.0025 + 6 mV
