6166 DC Voltage Current Source Operation Manual
1.2 Supplied Accessories
1-2
1.2 Supplied Accessories
The 6166 standard accessories are listed below. If any accessory is missing or damaged, contact an ADC
CORPORATION sales representative. Specify the part number when ordering.
1.3 Optional Accessories
The 6166 optional accessories are listed below. Specify the part number when ordering.
NOTE: Use the slide rail set or angle bars to mount the 6166 on the rack mount set. The rack mount set is not rigid
enough to support the instrument by itself. Using the slide rail set A02615 is recommended.
Contact an ADC CORPORATION sales representative for rack setup and other technical support.
Table 1-1 Standard Accessory List
Name Part number Quantity Remarks
Power cable
*1
A01402 1
Power fuse
*2
DFT-AA2R5A 1 100 V/120 V slow blow
DFT-AA1R25A 220 V/240 V slow blow
Operation Manual E6166 1 This manual
*1 : The power cable can be changed by specifying the option at the time of order.
For more information, refer to "Safety Summary."
*2 : Either of fuses is included depending on the power supply option.
Table 1-2 Optional Accessory List
Part number Description
A02615 Slide rail set for chassis C
CC028003 Front handle set (3U)
CC024003 Rack mount set (EIA 3U)
CC022003 Rack mount set (JIS 3U)
To Next Page
