6.2.1 Status Register
6-11
Common conditions in which the Device Event Status Register is cleared
• All cleared when the power is turned ON.
• All cleared by *CLS.
• All cleared when read by DSR?.
Conditions in which the Device Event Status Enable Register is cleared
• Cleared when the power is turned ON (the PSC flag is set to 1).
• Cleared when the DSE0 command is executed.
7MIL
Minus I Limiter
ON: Set to 1 when the negative current limiter is detected.
8EOP
Ext. Operate Off In
ON: Set to 1 when Operate is set to OFF by the interlock signal.
9 ETG
Ext. Trigger In
ON: Set to 1 when an external trigger signal input is detected.
10 Not in use Always set to 0.
11 OPR
Operate
ON: Set to 1 when Operate status is set.
OFF: Set to 0 when Standby status is set.
12 CAE
Calibration End
ON: Set to 1 when calibration is complete.
OFF: Set to 0 when calibration starts.
13 PSR
Program Scan Run
ON: Set to 1 when scan is complete.
OFF: Set to 0 when scan starts.
14 PSE
Program Scan End
ON: Set to 1 when scan starts.
OFF: Set to 0 when scan is complete or paused.
15 Not in use Always set to 0.
Table 6-3 Device Event Status Register (DSR) (2 of 2)
bit Name Description
