6166 DC V
oltage Curre
nt Source O
peration Manual
6.3.
3 Setti
ng GPIB
6-19
Press
or
to select the parameter
.
The highlight sectio
n switches as
Bus

Address

Header

Listen Only

616
1 Compati
.
Example display
Press
to
move to the Input/Run level.
Example display
Set the head
er to ON or OFF
by rotati
ng the rot
ary knob.
Example display
Press
to exit the menu
screen.
4
5
6
7
186
188
