6166 DC Voltage Current Source Operation Manual
9. SPECIFICATIONS
9-9
BCD parallel interface: Remote programming
Output level, polarity, range, Operate, V/I mode, divided output, voltage limit,
current limit, remote operate input, operate flag output, limit flag output
Connector Amphenol 50 pin
*Factory option
External control signal: TRIGGER IN
INTERLOCK
Connector BNC
General Specifications
Operating environment conditions: Ambient temperature 0ï€ ï‚°C to +50ï€ ï‚°C
Relative humidity 85 % or below, no condensation
Storage environment conditions: Ambient temperature -25ï€ ï‚°C to +70ï€ ï‚°C,
Relative humidity 85 % or below, no condensation
Warming up time: 60 minutes or longer (until the specified accuracy is reached.)
Display: Dot matrix vacuum fluorescent display
Power supply: AC power 100 V/120 V/220 V/240 V (User selectable)
Line frequency: 50 Hz/60 Hz
Power consumption: 90 VA or less
Dimensions: Approx. 424 (width) ï‚´ 132 (height) ï‚´ 450 (depth) mm
Mass: 17 kg or less
Safety: Compliant with IEC61010-1 Ed.3
EMI: Compliant with EN61326 classA
Supplied Accessory
Options
OPT6166+20 Compliance voltage 1200 V (1 mA and 10 mA ranges) (factory option)
OPT6166+04 BCD parallel interface (factory option)
Optional accessories
CC022003 Rack mount set 3U JIS
CC024003 Rack mount set 3U EIA
CC028003 Rack mount set 3U
A02615 Slide rail set
Option No. Standard OPT.32 OPT.42 OPT.44
Power voltage 100 V 120 V 220 V 240 V
Specify the option when ordering.
When changing the power voltage, use only a power cable and rated
fuse approved for the respective country.
Part number Name Quantity
A01402 Power cable (JIS 2 m) 1
