6166 DC Voltage Current Source Operation Manual
2.2 Screen Display (Annotations)
2-12
IL status Appears when the current limit is detected. Disappears when the
detection is released.
+I: +Current limit, -I: -Current limit
When the current limit is detected, the LIMIT key also goes ON
in red.
Source value Displays the source value that consists of the polarity, 7-digit val-
ue, decimal point and unit and the source function.
ERR Appears when error logs are stored.
Remote 1 RMT: Appears in remote control (except BCD remote con-
trol).
BCD: Appears in BCD remote control.
Remote 2 MA: Appears when the 6166 is addressed as Lister or
Talker in remote control .
: Appears when the 6161-compatible operation is set
to ON.
