6166 DC Voltage Current Source Operation Manual
3.5 Changing Source Function
3-19
The following is an example to select 10 V range of the voltage function and set the source value to
+10 V.
Press .
The 10 V range of the voltage function is selected and the source value is set to +10 V.
Example display
(2) Changing to the current function
Operating procedure
Check that the program function is set to OFF.
When the program function is set to ON, the PROGRAM key lights up. Pressing the PROGRAM
key sets it to OFF.
This is an example when auto range is selected. Press to select auto range.
When auto range is selected, the AUTO key lights up.
The source function and the source value are set simultaneously.
The following is an example to select the minimum range (1 mA range) of the current function and
set the source value to +0 mA.
Press .
The 1 mA range of the current function is selected and the source value is set to +0 mA.
Example display
4
1 2 3 4
1
2
3
