3.8 Program Function
3-28
3.8 Program Function
The program function is to previously save source data to the program memory that consists of 1000 data sets
and to recall them arbitrarily.
The following parameters can be saved in each memory number of the program memory.
Source function (voltage/current/divider voltage/thermal electromotive force)
Range (for voltage/current/divider voltage)
Source value
Voltage limit (for voltage function/current function)
Current limit (for voltage function/current function)
Type of thermocouple (for thermal electromotive force function)
JIS-C1602 1995/1981 for thermocouple (for thermal electromotive force function)
Reference junction temperature (for thermal electromotive force function)
How to recall the program memory is shown below.
The following table shows scan operations.
Table 3-7 Recalling Program Memory
Program Recall Description
Recall Recalls a specified memory number arbitrarily.
Scan Hold Outputs the source values from the specified first number to last number in order
by every trigger input.
The trigger input includes key, remote and external trigger input.
Single Outputs the source values from the specified first number to last number in order at
step time intervals.
Repeat Outputs repeatedly the source values from the specified first number to last num-
ber in order at step time intervals.
