Register Definitions B
E6198B Switch/Load Unit User Manual B-17
Load Select 1-8 (W) Base + 4
h
This register controls the Load Select switch armature relays for
channels 1- 8. The register uses positive logic: 1 = closed.
Writing to this register starts the armature relay timer.
• Write Only
• State: 1 = closed, 0 = open
• Power On/Reset State = 0
Load Select 9-16 (W) Base + 5
h
This register controls the Load Select switch armature relays for
channels 9-16. The register uses positive logic: 1 = closed.
Writing to this register starts the armature relay timer.
• Write Only
• State: 1 = closed, 0 = open
• Power On/Reset State = 0
Power Select 1-8 (W) Base + 6
h
This register controls the Pull Up/Down Power Select armature
relays for channels 1-8. These relays are Form C and the register
uses positive logic: 1 = NO shorted to COM, NC is open; 0 = NC
Select 9 10 11 12 13 14 15 16
Relays
K17,
K18
K19,
K20
K21,
K22
K23,
K24
K25,
K26
K27,
K28
K29,
K30
K31,
K32
Bit 76543210
Purpose
K56
CH 8
K54
CH 7
K52
CH 6
K50
CH 5
K48
CH 4
K46
CH 3
K44
CH 2
K42
CH 1
Setting state state state state state state state state
Bit 76543 21 0
Purpose
K72
CH 16
K70
CH 15
K68
CH 14
K66
CH 13
K64
CH 12
K62
CH 11
K60
CH 10
K58
CH 9
Setting state state state state state state state state
