B-18 E6198B Switch/Load Unit User Manual
B Register Definitions
shorted to COM, NO is open. The power buses selected depend
upon how the card is configured by the user. Writing to this
register starts the armature relay timer.
• Write Only
• State: 1 = NO shorted to COM, NC open; 0 = NC shorted to
COM, NO open
• Power On/Reset State = 0
Power Select 9-16 (W) Base + 7
h
This register controls the Pull Up/Down Power Select armature
relays for channels 9-16. These relays are Form C and the
register uses positive logic: 1 = NO shorted to COM, NC is open;
0 = NC shorted to COM, NO is open. The power buses selected
depend upon how the card is configured by the user. Writing to
this register starts the armature relay timer.
• Write Only
• State: 1 = NO shorted to COM, NC open; 0 = NC shorted to
COM, NO open
• Power On/Reset State = 0
Bit 76543210
Purpose
K55
CH 8
K53
CH 7
K51
CH 6
K49
CH 5
K47
CH 4
K45
CH 3
K43
CH 2
K41
CH 1
Setting state state state state state state state state
Bit 76543210
Purpose
K71
CH 16
K69
CH 15
K67
CH 14
K65
CH 13
K63
CH 12
K61
CH 11
K59
CH 10
K57
CH 9
Setting state state state state state state state state
