B-40 E6198B Switch/Load Unit User Manual
B Register Definitions
Load Select 1 & 2 (W) Base + 6
h
This register controls the power selection relays for channels 1
and 2 with four possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 3 & 4 (W) Base + 7
h
This register controls the power selection relays for channels 3
and 4 with four possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 5 & 6 (W) Base + 8
h
This register controls the power selection relays for channels 5
and 6 with four possible loads on each channel.
Bit 76543 210
Purpose
Chan2.4 Chan2.3 Chan2.2 Chan2.1 Chan1.4 Chan1.3 Chan1.2 Chan1.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan4.4 Chan4.3 Chan4.2 Chan4.1 Chan3.4 Chan3.3 Chan3.2 Chan3.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan6.4 Chan6.3 Chan6.2 Chan6.1 Chan5.4 Chan5.3 Chan5.2 Chan5.1
Setting state state state state state state state state
