E6198B Switch/Load Unit User Manual B-41

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 7 & 8 (W) Base + 9

This register controls the power selection relays for channels 7

and 8 with four possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 9 & 10 (W) Base + A

This register controls the power selection relays for channels 10

and 9 with four possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Bit 76543 210

Purpose

Chan8.4 Chan8.3 Chan8.2 Chan8.1 Chan7.4 Chan7.3 Chan7.2 Chan7.1

Setting state state state state state state state state

Bit 76543 210

Purpose

Chan10.4 Chan10.3 Chan10.2 Chan10.1 Chan9.4 Chan9.3 Chan9.2 Chan9.1

Setting state state state state state state state state
