B-42 E6198B Switch/Load Unit User Manual
B Register Definitions
Load Select 11 & 12 (W) Base + B
h
This register controls the power selection relays for channels 12
and 11 with four possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 13 & 14 (W) Base + C
h
This register controls the power selection relays for channels 14
and 13 with four possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 15 & 16 (W) Base + D
h
This register controls the power selection relays for channels 16
and 15 with four possible loads on each channel.
Bit 76543 210
Purpose
Chan12.4 Chan12.3 Chan12.2 Chan12.1 Chan11.4 Chan11.3 Chan11.2 Chan11.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan14.4 Chan14.3 Chan14.2 Chan14.1 Chan13.4 Chan13.3 Chan13.2 Chan13.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan16.4 Chan16.3 Chan16.2 Chan16.1 Chan15.4 Chan15.3 Chan15.2 Chan15.1
Setting state state state state state state state state
