E6198B Switch/Load Unit User Manual B-43

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 17 & 18 (W) Base + E

This register controls the power selection relays for channels 18

and 17 with four possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 19 & 20 (W) Base + F

This register controls the power selection relays for channels 20

and 19 with four possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Bit 76543 210

Purpose

Chan18.4 Chan18.3 Chan18.2 Chan18.1 Chan17.4 Chan17.3 Chan17.2 Chan17.1

Setting state state state state state state state state

Bit 76543 210

Purpose

Chan20.4 Chan20.3 Chan20.2 Chan20.1 Chan19.4 Chan19.3 Chan19.2 Chan19.1

Setting state state state state state state state state
