E6198B Switch/Load Unit User Manual B-53

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 29-32 (W) Base + D

This register controls the power selection relays for channels 29

through 32 with two possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Load Select 33-36 (W) Base + E

This register controls the power selection relays for channels 33

through 36 with two possible loads on each channel.

• Write Only

• State:

1 = closed

0 = open

• Power On/Reset State = 0

Bit 76543 210

Purpose

Chan32.2 Chan32.1 Chan31.2 Chan31.1 Chan30.2 Chan30.1 Chan29.2 Chan29.1

Setting state state state state state state state state

Bit 76543 210

Purpose

Chan36.2 Chan36.1 Chan35.2 Chan35.1 Chan34.2 Chan34.1 Chan33.2 Chan33.1

Setting state state state state state state state state
