B-54 E6198B Switch/Load Unit User Manual
B Register Definitions
Load Select 37-40 (W) Base + F
h
This register controls the power selection relays for channels 37
through 40 with two possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 41-44 (W) Base + 10
h
This register controls the power selection relays for channels 41
through 44 with two possible loads on each channel.
• Write Only
• State:
1 = closed
0 = open
• Power On/Reset State = 0
Load Select 44-48 (W) Base + 11
h
This register controls the power selection relays for channels 45
through 48 with two possible loads on each channel.
Bit 76543 210
Purpose
Chan40.2 Chan40.1 Chan39.2 Chan39.1 Chan38.2 Chan38.1 Chan37.2 Chan37.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan44.2 Chan44.1 Chan43.2 Chan43.1 Chan42.2 Chan42.1 Chan41.2 Chan41.1
Setting state state state state state state state state
Bit 76543 210
Purpose
Chan48.2 Chan48.1 Chan47.2 Chan47.1 Chan46.2 Chan46.1 Chan45.2 Chan45.1
Setting state state state state state state state state
