9500 MXC User Manual
3DB 23063 ADAA - Rev 004 July 2007 Vol. II-3-115
Co-Channel 64xE1 Ring Node
Figure 3-65 illustrates co-channel ring operation.
• 9500 MXC Super-PDH ring operation provides the ring protection mechanism.
For single gateway rings 64xE1 or 84xDS1 are the ring capacity maximums.
Figure 3-65. Co-Channel 64xE1 Ring Node with 16xE1 Drop-Insert
Fan
NCC
INU
INU
16xE1
64xE1 (V)
64xE1 (H)64xE1 (H)
V
V
HH
XPIC Cross-Connect Cables
ODU 300
ODU 300
ODU 300
ODU 300
Fan
NCC
DAC 16x
64xE1 (V)
RAC 40
RAC 40 RAC 40
RAC 40
128xE1128xE1
16xE1
Ring Network
West East
