Allen-Bradley CompactLogix 5480 User Manual

158 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 7 Use I/O Modules
The following are example factors that you must consider when you decide
how to use local I/O modules in a CompactLogix 5480 system:
• Number of local I/O modules that the controller supports
• Features available on different modules, for example, sequence of events
per point timestamping on only some Compact 5000 digital input
modules
• I/O module power usage, including MOD power and SA power
For more information on Compact 5000 I/O modules, see
Additional
Resources on page 10.
Figure 22 - Local I/O Modules in a CompactLogix 5480 System
™
NET B1
LINK B1
NET A1
LINK A1
NET A2
LINK A2
SPEED X1
LINK X1
OK
RUN
FORCE
FAN 1
SD
FAN 2
CompactLogix 5480
B1
A1
1
2
A2
5069-L46ERMW
CONTROLLER
UPS
MP
SA
R
B
F
R
B
F
DC INPUT
5069-IB16
DC OUTPUT
5069-OB16
ANALOG INPUT
5069-IY4
ANALOG OUTPUT
5069-OF8
DC INPUT
5069-IB16
Local I/O Modules
