182 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019

Chapter 8 Develop Control Applications

Figure 28 - Tasks

A task provides scheduling and priority information for a set of one or more

programs. Use the Task Properties dialog box to configure tasks as continuous,

periodic, or event.

Figure 29 - Configuring the Task Type

Main Task

(continuous)

Task 2

(periodic)

Main Task

(continuous)

Task 2

(periodic)

Controller Organizer

Logical Organizer
