Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 217

Commercial Operating System Chapter 10

DisplayPort

The DisplayPort interface lets you connect the controller to a display monitor

that can be used with the COS.

If you want to connect to a monitor using a different interface, you must us a

VESA-certified DisplayPort adapter or cable.

Failure to use a VESA-certified adapter can cause damage or improper

operation. For a list of certified adapters and cables, see

www.vesa.org.

Figure 47 - Connect a Cable to the DisplayPort

FAN 2 - BOTTOM

5069-L46ERMW

CONTROLLER

NET B1

LINK B1

NET A1

LINK A1

NET A1

NET A2

SPEED X1

LINK X1

RUN

FORCE

FAN 1

FAN 2

™

CompactLogix 5480

UPS
