Configuring the inner sections control mode
The inner sections control mode describes the overlap of
the inner
part-width sections. The overlap defines how
far the part-width sections can protrude into the already
worked areas before the sections are switched off.
Example settings Explanation Figure
0 %
The part-width sections are switched
of
f before any overlap occurs.
50%
The part-width sections are switched
of
f when they half protrude into the
worked area.
100%
The part-width sections are switched
when they fully protrude into the
worked area.
009858
P | Using part-width section control| Using automatic part-width section control
MG5574-EN-II | B.1 | 25.10.2016
188
